The durable hoods and frame and the compact radius design of the 304E2 let you work comfortably and confidently in confined areas. The operator environment includes a high quality suspension seat, easy to adjust armrests and 100% pilot controls which offer consistent and long-lasting controllability.
High Definition Hydraulic System provides a load sensing and flow sharing capability leading to operational precision, efficient performance and greater controllability. Power on Demand provides optimal efficiency and performance the moment you need it. This automatic system ensures fuel efficiency through appropriate engine rating to meet all operational needs as required.
FULL SPECIFICATIONS
ENGINE
| Net Power |
40.2 HP |
| Engine Model |
Cat C2.4 |
| Note |
The Cat C2.4 meets U.S. EPA Tier 4 Final emission standards for North America, EU Stage V emission standards for Europe and Tier 4 Interim emission standards for all other regions. |
| Net Power – 2,200 rpm – ISO 9249/EEC 80/1269 |
40.2 HP |
| Displacement |
146 in³ |
| Stroke |
4 in |
| Bore |
3.4 in |
| Gross Power – ISO 14396 |
41.8 HP |
WEIGHTS*
| Operating Weight |
8996 lb |
| Weight – Canopy, Standard Stick |
8655 lb |
| Weight – Canopy, Long Stick |
8721 lb |
| Weight – Cab, Long Stick |
8996 lb |
| Weight – Cab, Standard Stick |
8930 lb |
TRAVEL SYSTEM
| Maximum Traction Force – High Speed |
3799 lb |
| Maximum Traction Force – Low Speed |
6969 lb |
| Travel Speed – High |
3.2 mile/h |
| Travel Speed – Low |
2.1 mile/h |
| Ground Pressure – Canopy |
4.1 psi |
| Ground Pressure – Cab |
4.3 psi |
BLADE
| Width |
76.8 in |
| Height |
12.8 in |
| Dig Depth |
18.5 in |
| Lift Height |
15.7 in |
SERVICE REFILL CAPACITIES
| Cooling System |
1.5 gal (US) |
| Engine Oil |
2.5 gal (US) |
| Hydraulic Tank |
11.2 gal (US) |
| Fuel Tank |
12.2 gal (US) |
| Hydraulic System |
17.2 gal (US) |
OPTIONAL EQUIPMENT
ENGINE
HYDRAULIC SYSTEM
- Boom lowering check valve
- Stick lowering check valve
- Secondary auxiliary hydraulic lines
OPERATOR ENVIRONMENT
- Cab:
- Air conditioning
- Heat
- High back suspension seat
- Interior light
- Interlocking front window system
- Radio
- Windshield wiper
UNDERCARRIAGE
- Track, double grouser (steel), 350 mm (14 in)
FRONT LINKAGE
- Quick coupler: manual or hydraulic
- Full range of performance matched work tools
LIGHTS AND MIRRORS
- Light, cab with time delay capability
SAFETY AND SECURITY
